High-Quality Curtain Wall Cladding Details Suppliers – Powder Coated&PVDF Aluminium Stick Frame Curtain Wall Glass Facade system – Deshion Detail:
Main Characteristic of Stick Curtain Wall
1.The construction method is flexible and the technology is relatively mature, this curtain wall structure form is widely used at present after more engineering practice tests.
2.The main structure has strong adaptability, and the installation sequence is basically not affected by the main structure.
3.Using sealant joint processing, good water tightness and air tightness. It is preferable for heat preservation, sound insulation and noise reduction, also with a certain resistance to inter-layer displacement.
4.Panel material unit components are finished in the factory, structural adhesive performance is guaranteed.
5.A large number of installation processes are carried out on site, requiring heavy workload of site management.
6.Sealant construction demands are strict, early cleaning, gluing process need high quality requirement of workers.
Component Fully-Hidden Frame Glass Curtain Wall
|
Standard products |
Product standardization, serialized design, stable and reliable quality, can meet different requirements. |
|
Structure features |
Positioning installation, distance pressing structure, uniform force on the glass plate; Plate floating connection structure, strong in-plane displacement absorption capacity. |
|
Water tightness Air tightness |
Weather resistant sealant caulking, water tightness and air tightness can reach (GB/T15225-94) I class standard. |
|
Architectural effect |
The facade is flat and simple |
|
Thermal insulation properties |
Foam rod is used to fill the air cavity, weatherproof sealant is caulked, so that the heat transfer coefficient Uf of the frame can reach 1.7W/m2K. |
Component Half-Hidden Frame Glass Curtain Wall
|
Standard products |
It can be installed and disassembly freely |
|
Structure features |
The glass is mainly subjected to wind pressure by the hook plate on the four sides. The design of structural sealant makes the structure have double safety protection function |
|
Architectural effect |
The outer line of sight is concise and lively, with good permeability |
Stick Curtain Wall
The mullion (or beam) of the stick curtain wall is installed on the main structure first, and then the beam (or mullion) is installed.
Mullions and beams form a lattice, Panel materials are processed into unit components in the factory, then fixed on the frame lattice composed of mullion and beam.
The load borne by the panel material unit components is transmitted to the main structure through mullions (or beams).
The common form of the structure is that the mullions and cross beams are installed on site to form a lattice and the panel material unit components are fixed on the skeleton, The panel material unit component is vertically connected to the column and horizontally connected to the beam and use sealant joint processing to prevent rain seepage and air infiltration.
Site Installation
Paste On Site
Stick And Unitized Curtain Wall Flow Chart
Unitized Curtain Wall Lifting
Stick Curtain Wall Installation
Unitized Curtain Wall Lifting
Stick Curtain Wall Installation
Stick Curtain Wall Construction Technology
|
NO. |
Item |
Quality standard |
|
1 |
Column mounting |
The elevation difference between two adjacent columns is less than or equal to 5mm. The distance difference between two adjacent columns is less than or equal to 2mm |
|
2 |
Beam installation |
The levelness deviation of the beam is less than or equal to 2mm, the horizontal elevation difference of the two adjacent beams is less than or equal to 1mm, the distance deviation of the two adjacent beams is less than or equal to 2mm, and the height difference of the main beam within the same height is less than or equal to 5mm. |
System Performance
|
01 |
Sound resistance Rw to 48 dB |
02 |
Wind and water tightness to 1000 Pa (depending on design) |
|
03 |
Column mounting |
04 |
High thermal insulation (depending on design) |
|
05 |
Beam installation |
06 |
High glass weights to 300KG |
|
07 |
View width 60mm |
08 |
Different cover caps on the outside |
|
09 |
Inside and outside color as desired |
||
System Performance
Curtain walls have the primary purpose of keeping air and water out of the building, essentially acting as both a buffer and an insulator. Unlike continuous windows, which are smaller units and can rely to a high degree on sill flashings to capture frame corner leakage, curtain walls cover large expanses of wall without sill flashings at each glazed opening. Deshion especially patented curtain wall system water penetration resistance high to 1000 Pa.
Curtain Wall Design Performance Index
Stick Curtain Wall
Waterproofing is generally a single channel seal, it can not form a double seal. The probability of water seepage is 2 times of unitized curtain wall.
Unitized Curtain Wall
Double channel sealing system, adapted to the main structure of the larger displacement requirements. It can ensure the building has excellent curtain wall performance (air tightness, water tightness, thermal insulation, in-plane deflection, etc.).
*Unitized curtain wall adopts “isobaric principle”, waterproof performance is good
Insulation Design of Unitized Curtain Wall
Curtain Wall And Glass Testing
Curtain wall with lighting function requirements, the transmittance reduction factor should not be less than 0.45. Curtain wall with color discrimination requirements, its color perspective index should not be lower than Ra80
The curtain wall shall be able to support its own weight and the weight of various accessories in the design, and can be reliably transferred to the main structure
The maximum deflection of the horizontal stressed member within the span at both ends of a single panel under standard dead weight should not exceed 1/500 of the span at both ends of the panel, and not exceed 3mm
Curtain wall tempered glass should be processed by hot dip. Secondary heat treatment, soaking heat treatment, detonation treatment, “after treatment can be less than 1/1000 of the self-explosion rate” is commonly used in engineering
Infrastructure is an integral part of urban development, Deshion can also provide you with one-stop solutions for municipal engineering
Municipal Guardrail
Public Utilities
Facility Fence Mesh Series
Municipal Guardrail
Municipal Guardrail
City Road Guardrail
Sidewalk Guardrail
Noise Barrier Series
Corrugated Beam Guardrail
River Guardrail
Municipal Facilities Park Guardrails
The application of municipal guardrails in our lives is very common. Guardrails not only play a protective role, but also play a decorative role.
There are many kinds of municipal guardrails, and the functions of different guardrails are different, and we can customize the function and appearance according to your needs.
Public Utilities
Public Utilities
Bus Platform
Steel Structure Gazebo
Sidewalk Awning
Park Benches
Bicycle Parking Rack
Public Fitness Facilities
The role of public facilities is to meet people’s public needs (such as convenience, safety, participation) and the choice of public space.
Facility Fence Mesh Series
Facility Fence Mesh Series
Double Wire Fence
Chain Link Fence
Double Horizontal Wire Fence
Y-Shaped Safety Fence
Temporary Fence
Highway Anti-Glare Fence
Fences are usually made of high-strength welded wire mesh or weaving technology (Chain Link Fence), which has the characteristics of simple structure, convenient installation, strong durability and so on.
It is often used for large-area enclosures of roads, railways, green belts, stadiums, airports, farms, construction sites, border ports, municipalities and other venues.
One-stop solution service,overseas installation service available.
Curtainwall System
Window&Doors
Railing
Steel Strycture
Regular Batch
Curtainwall System
Glass Curtain Walling
Full Glass Window Walls
Point Supported Glass Curtain Walls
Stick Curtain Wall Systems
Unitized Aluminum Curtain Walls
Metal Curtain Wall
Window&Doors
Aluminium Frame Doors
Casement Doors
Sliding Doors
Folding Doors
Aluminium Frame Windows
Casement Windows
Sliding Windows
Tilt And Turn Windows
Railing
Fence/Railing
Wrought Iron Railings
Stainless Steel Handrails
Glass Balustrades
Aluminum Handrails
Steel Strycture
Steel Systems
Portal Type Steel Structure Systems
Multi-Storey Type Steel Structure
Grid Space Steel Structure Systems
Steel Truss Systems
Regular Batch
Railing / Handrail / Fence Wholesale
Market Guardrail Series Wholesale
Metal Mesh Wholesale
Guardrail / Railing Wholesale
Fence Wholesale
Packaging & Shipping
Free Customized Design
We design complex industrial buildings for clients using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures(Xsteel)and etc.
Customization Process
Production Workshop Overview
Iron Workshop
Raw Material Zone 1
Aluminum Alloy Workshop
Raw Material Zone 2
Robotic Welding Machine Installed In New Factory
Automatic Spraying Area
Multiple Cutting Machines
Certification Authority
Cooperative Company
FAQ
1.What’s your manufacturing time?
38-45 days depends upon down payment received and shop drawing signed
2. What makes your products different from other suppliers?
Strictly quality control and very competitive price as well as professional sales and installation engineering services.
3. What is the quality assurance you provided and how do you control quality?
Established a procedure to check products at all stages of the manufacturing process – raw materials, in process materials, validated or tested materials, finished goods, etc
4. How to get the accurate quotation?
If you can provide the following project data, we are able to offer you with accurate quotations.
Design code/ design standard
Column position
Maximum wind speed
Seismic load
Maximum snow speed
Maximum rainfall
